VT608 / Switching PDU
MSRP price: €449.00
Device is used for load management and allows to switch on/off or reboot up to 8 outlets.
It has built-in temperature sensor, can connect two additional sensors and 2 dry contacts, two 12V devices (for example, alarm beacons), GSM modem and USB-сam.
There are built-in servers and agents like HTTP, HTTPS, SNMP v1, 2c, 3, SMTP, Radius, Syslog, FTP, DHCP, Wachdog.
8 switched outlets
VT608 has 8 switched outlets. They can be controlled individually or as a group using web interface. Outlets can also be managed with predefined logic.
LEDs on front panel
LEDs for indication of outlet status, appliance status, electronic relay status, CAN status and errors.
Sensors ports
Connect sensor by a supplied RJ-11 (6P4C) cable to any"A1 - A2" port. Determination of the sensor type and connection will occur automatically.
CAN port
Connecting CAN devices on a common bus allows you to collect data from the sensors with a large area, or from a large distance and to transmit them to the network.
12V outputs for alarms
Appliance has the possibility to connect flash lights or sirens managed by built-in electronic relay.
Temperature sensor
Temperature sensor is built-in on a board and sticks out on the front panel of the unit for better measurement. Accuracy equals +/- 1°C.
Dry contact inputs
VT604 has 2 dry contact inputs. Can be used together with any contacts, for example with door or window contacts, circuit breakers etc.
Extension: GSM modem
VT604 has the possibility to install GSM modem. It is used for sending SMS notifications and receiving SMS commands.
USB camera
USB camera (class Linux UVC Webcam which supports MPEG) can be connected to "HS" port.
IP cameras
Using built-in interface it is possible to add up to four IP cameras. This will allows to view footagefrom surveillance cameras remotely,
USB flash drive
USB flash drive can be connected to VT805 using OTG miniUSB cable and can be used by the system for saving logs. More USB devices can be connected to one HS USB port using USB hub.
LAN
Ethernet 10/100 Base-T port, provides network connection.
Data sheet
- Product dimensions
- 440 x 44.45 (1U) x 79 mm
- Packaging weight
- 1,5 kg
- Power input
- 2 inlets C14, 240V, 10A
- Power Consumption
- 10 Watt
- Operating temperature
- Temperature : Min. -10° C - Max.+80° C
- Other
- Recovery switch
Restart button - Mounting possibilities
- 19" rack mountable
Desktop
Wall turnable mount (with extension) - Max. distance from the unit
- 225 m
- Manufactured in (country)
- Manufactured in Slovak Republic, E.U.
- HS Code
- 8471 50 000
- Package includes
- 19" mounting brackets 2pcs
Cable EU Schuko C13 0.5mm2 230V 10A
Patch cable RJ-45 1m
Screws 6pcs M3 8mm
Self-adhesive rubber foot 4 pcs
Short description and connection guide
Terminal plug 3 pins 3.5mm 1pcs
Terminal plug 3 pins 3.81mm 1pcs
Warranty card - Brackets (accessories)
- VT112 / Rotatable mounting brackets (ordered separately)
- Inputs terminals
2 inlets C14 (240V, 10A)
Analog sensor ports: x2 ports
CAN bus sensor port
Dry contacts / Digital inputs: 2 contacts (pitch 3,5mm, type IN)- Expansions (ordered separately) *
- VT700 / GSM modem
- Processor *
- ARM926-300 MHz / 64 MB / Linux-2.6.38
- Extension protocols *
- CAN
- Network Interface *
- CAN bus
CAN open
Ethernet 10/100 Mbit/s - Built-in sensors *
- Power supply voltage sensor (1%)
Temperature sensor (Accuracy 1%) - Outputs terminals
- 8 outlets C13
SMA GSM
Two 12V 0,25A outputs (pitch 3,81mm, 3P) - Status Indicators *
- 8 orange LEDs for outlet status
Error LED
LED indication for CAN bus connection
LED indication for Power / Network connectivity
Two relay status LEDs
