VT520DIN AC Voltage Monitor
Previous
Next
Description
The additional power supply is needed only if the number of sensors in a CAN bus chain is more than 12 sensors. CAN-12V-1A supplies power for each additional group of 12 CAN devices (sensors and extensions).
CAN devices and sensors can be chained together. Up to 10-32 CAN devices can be connected in a chain. You can connect CAN sensors or extensions on a CAN bus line.
Use cases
The VT594 Water Leak Sensor is used for:
- Data Center Monitoring: The VT520 can be utilized in data centers to continuously monitor AC voltage levels across multiple racks. This ensures that servers and networking equipment receive stable voltage, helping to prevent potential equipment failure due to voltage fluctuations.
- Industrial Equipment Monitoring: In manufacturing environments, the VT520 can monitor the voltage supplied to heavy machinery. Accurate voltage measurement helps operators maintain optimal performance and prevent downtime caused by electrical issues.
- Building Management Systems: The voltmeter can be integrated into building management systems to monitor voltage levels for HVAC systems, lighting, and other electrical equipment. This aids in energy management and can trigger alarms if voltage levels fall outside specified thresholds.
- Electrical Panels: When installed in electrical distribution panels, the VT520 can provide real-time voltage monitoring to electricians and facility managers, allowing for quick diagnosis of electrical problems.
- Power Quality Analysis: The sensor can be used for power quality assessments, helping to identify issues like voltage sags, swells, and harmonics that can affect overall system performance and equipment longevity.
- Renewable Energy Systems: In solar or wind energy systems, the VT520 can monitor AC voltage output to ensure that the generated energy is within safe operational limits for connected devices.
- Research and Testing: In laboratories or testing facilities, the VT520 can be used to conduct experiments or tests on electrical devices, providing precise voltage readings necessary for accurate data collection.
Specifications
Type of sensor:
Analog sensor
Measures:
DC voltage
Measured voltage:
0-246V, AC
Accuracy:
1%.
Daisy chain:
No
Protection:
IP20H / IP40H
Dimensions:
DIN 2M, Height 90.2mm, Width 36.3mm, Depth 57.5mm
Cable length:
6P4C RJ11 Telephone cable included, 2m.
Power consumption:
60 mW
Operating temperature:
Optimal temperature range: -10° C to +80° C
Operating humidity:
5 to 95 % (Non-Condensing)
Inputs:
Strip length 6-7mm, Wire cross 2.5mm ² 22~12AWG
Outputs:
x1 autosense port, RJ-11 (6P4C), Output 0-5V
Mounting possibilities:
DIN rail height 35 mm, DIN rail depth 7mm and 15mm
Max. distance from the unit:
100 m
Manufactured in:
Slovak Republic, E.U.
HS Code:
9030 33 100
EAN:
8588009886150
Previous
Next
Sensor features
Logic schemes
Logic schemes are used to specify automatic actions to events that occur in the system.
Dashboard view
The system allows to customize the dashboard individually for each user and displays the most important information on it in a visual form.
Add widgets with multi graphs, gauge meters or knobs.
Thresholds
Each sensor has Low Alarm, Low Warning, Normal, High Warning, and High alarm threshold states for logic control & sending of notification.
Graphs and Logging
Vutlan supports SD card logging up to 500 Gb. You can log a whole systems loaded with sensors for 3 years.
Previous
Next
Add more analog sensors using VT408 or VT408DIN
'VT408 Sensor extension unit' and 'VT408DIN Sensor extension unit" increase the number of analog sensors connected to any Vutlan monitoring unit. Each VT408 unit adds 8 analog sensors. Multiple VT408 units can be connected using a daisy CAN chain. Sensors connected to the extension unit appear in the system automatically.
Systems with analog ports:
To read data from the analog sensors, you need Vutlan monitoring and control system. All the following monitoring & control systems have a different amount of analog ports.
