VT960ii / Redundant monitoring unit

MSRP price: €1,239.00

The unit is used for environmental monitoring (e.g. temperature, humidity, voltage, leakage, smoke, airflow). It is also used as an I/O controller (e.g. door control, fans, generator, control panels, UPS, circuit breakers, alarms). Can use up to 1000 elements - notifications, triggers, timers, logic schemes, sensors, dry contacts. Has a built-in Web interface with virtual sensors, logic schemes, different types of notifications, and control panels.

Has a slot for a "VT790 / LTE slot modem" (Ordered separately!) and a 2.5" HDD. This is the fastest and most powerful Vutlan monitoring unit.

Order options:

VT960ii with x2 power inlets, providing a redundant power supply for A&B power distribution systems (e.g. data centers).

Power input:
Extension:
warranty

Data sheet

Product dimensions
1U Rack mount, 440 mm
Depth 110 mm
Height 44mm
Packaging weight
1.8 kg
Power input
+/- 24 / 48V
1 inlet C14, 240V, 10A
Operating temperature
Temperature : Min. -10° C - Max.+80° C
Mounting possibilities
19" rack mountable
Max. distance from the unit
225 m
Manufactured in (country)
Manufactured in Slovak Republic, E.U.
HS Code
8471 50 000
Package includes
19" mounting brackets 2pcs
Cable EU Schuko C13 0.5mm2 230V 10A
Patch cable RJ-45 1m
Screws 6pcs M3 8mm
Self-adhesive rubber foot 4 pcs
Short description and connection guide
Terminal plug 3 pins 3.81mm 1pcs
Warranty card
Device management
Any infrastructure management software with support for SNMP v1, v2c, v3
Web Interface using any browser
Brackets (accessories)
VT112 / Rotatable mounting brackets (ordered separately)
Inputs terminals
1 inlet C14 (240В, 10А)
1-Wire (iTouch reader)
Analog sensor ports: x8 ports
CAN bus sensor port
Dry contacts / Digital inputs: 16 contacts
SATA
Expansions (ordered separately) *
2,5" SATA HDD
VT48 / Dry contacts board
Processor *
Dual-core ARM Cortex-A7 / 1GHz / 1GB / Debian Linux
Extension protocols *
1-Wire
CAN
Network Interface *
1-Wire
CAN open
Ethernet 10/100 Mbit/s
Built-in sensors *
Temperature sensor (Accuracy 1%)
Outputs terminals
SD card slot
Two 12V 0,25A outputs (pitch 3,81mm, 3P)
Status Indicators *
Error LED
LED indication for CAN bus connection
LED indication for Power / Network connectivity
Two relay status LEDs

Download

VT960 VT960DC Brochure EN

Download (1.77MB)
