Increases the number of sensors connected to any monitoring unit. Adds x8 analog sensors. Connects on CAN port and allows further CAN daisy chain connection. Sensors connected to the extension unit appear in the system automatically.
Max. distance from the monitoring unit is 225 meters. Max. x8 CAN devices can be connected to a CAN bus chain.
VT572 / Radar motion sensor
A high-performance sensor/detector using microwave radar as a control signal source to detect objects or human movement. This product is an indoor energy-saving high-sensitivity detector.
The scanned signal can penetrate plastic, glass, ceiling, wooden door, and thin walls.
The detector is analog and it is connected to analog ports of the Vutlan monitoring system.
The amount of VT572 sensors can be extended using VT408 / Sensor extension unit or VT408DIN / DIN sensor extension unit.

A high-performance sensor/detector using microwave radar as a control signal source to detect objects or human movement. This product is an indoor energy-saving high-sensitivity detector.
The scanned signal can penetrate plastic, glass, ceiling, wooden door, and thin walls.
The detector is analog and it is connected to analog ports of the Vutlan monitoring system.
The amount of VT572 sensors can be extended using VT408 / Sensor extension unit or VT408DIN / DIN sensor extension unit.
related products
Increases the number of analog sensors connected to any Vutlan monitoring unit. Each unit connected adds 8 analog sensors. Connects on CAN port and allows further CAN daisy chain connection. Sensors connected to the extension unit appear in the system automatically.
Up to x24 VT408 units can be connected on a CAN bus line. CAN-12V-1A / CAN Power Supply has to be used to provide additional power on a CAN bus line.
VT123 / Wall mount brackets (ordered separately)
VT125t / 19” Mounting kit for x2 VT408 units (ordered separately)
