A microwave radar high-performance sensor is used for the detection of objects or human movement. This product is an indoor energy-saving high-sensitivity detector.
The scanned signal can penetrate plastic, glass, ceiling, wooden door, and thin walls.
The maximum amount of VT572 sensors connected to the Vutlan monitoring unit and maximum length can be extended using "VT408 / Sensor extension unit" or
Why Microwave motion sensor? Quick response time, Higher accuracy than PIR, The scanned signal can penetrate plastic, glass, ceiling, wooden door, and thin walls. This microwave motion sensor reflects the latest development in motion detection technology.
A microwave radar high-performance sensor is used for the detection of objects or human movement. This product is an indoor energy-saving high-sensitivity detector.
The scanned signal can penetrate plastic, glass, ceiling, wooden door, and thin walls.
Allows increasing the number of sensors connected to any monitoring unit. Adds 8 analog sensors. Connects on CAN port and allows further CAN daisy chain connection. Sensors connected to the extension unit appear in the system automatically.
Increases the number of sensors connected to any monitoring unit. Adds x8 analog sensors. Connects on CAN port and allows further CAN daisy chain connection. Sensors connected to the extension unit appear in the system automatically.
Max. distance from the monitoring unit is 225 meters. Max. x8 CAN devices can be connected to a CAN bus chain.
Monitoring system with redundant power supply
The unit is used for environmental monitoring (e.g. temperature, humidity, voltage, leakage, smoke, airflow). It is also used as an I/O controller (e.g. door control, fans, generator, control panels, UPS, circuit breakers, and alarms). Can use up to 1000 elements - notifications, triggers, timers, logic schemes, sensors, and dry contacts. Has a built-in Web interface with virtual sensors, logic schemes, different types of notifications, and control panels. Has a slot for a VT740 LTE Slot modem (ordered separately!) for an ethernet connection reservation.
Order options:
VT855i x1 230V AC power inlet
VT855ii x2 230V AC power inlets
VT855iDC x1 230V AC and x1 24-48V DC power inlets
VT855DC x1 24-48V DC power inlet
VT855DCDC x2 24-48V DC power inlets.ts.
Monitoring system with redundant power supply
The unit is used for environmental monitoring (e.g. temperature, humidity, voltage, leakage, smoke, airflow). It is also used as an I/O controller (e.g. door control, fans, generator, control panels, and alarms). Can use up to 1000 different elements - notifications, triggers, timers, logic schemes, sensors, dry contacts. Has a built-in Web interface with virtual sensors, logic schemes, different types of notifications, and control panels.
Has a slot for a VT740 LTE Slot modem (ordered separately!) for an ethernet connection reservation.
Order options:
VT825i x1 230V AC power inlet
VT825ii x2 230V AC power inlets
VT825iDC x1 230V AC and x1 24-48V DC power inlets
VT825DC x1 24-48V DC power inlet
VT825DCDC x2 24-48V DC power inlets.
